ULTRASONIC THICKNESS GAUGE SUPPLIERS
Thickness Gauge
Gauge Description:
Ultrasonic thickness gauge suppliers.
For more information on how to use the TG-22 (standard gauge) and TG-26 (high precision multi-mode, please request a quotation and manual. This standard type ultrasonic thickness gauge and multi-mode gauges are also available for special applications with optional transducers.
For a coating thickness gauge, paint thickness gage and thin film coating gauges, please specifically mention in your request that the application is for coating thickness and not our standard thickness gauges of multi-mode gauges.
The EESIFLO TG-22 is an easy to use standard industrial type ultrasonic thickness gauge.
Features:
High measuring range 1.2 mm…230.0mm (Steel)
Built in calibration test block
Small and light weight . Data logging capable
Metric & imperial versions available (switchable setting)
Easy operation . Aluminium Casing.
Typical Applications:
Access wall thickness of material due to corrosion.
Wall thickness measurements of hard materials, piping, sheet metal, construction materials
Hull plates and metallic surfaces
General inspection of metals including steel, cast iron,
Thickness of  aluminium, copper, brass, titanium sheet metal, tanks, ship metal, ship hull
Inspection of piping systems
Inspection of glass, ceramics and hard plastics
Resolution: 0.1mm
Display: 4 digit LCD
Accuracy: ±0.05mm (below 10mm) 0.1mm above 10mm.
Battery: Two AA sized cells.
Probe Operating temperature: 0…50 °C
Calibration block:
Auto Power Off:
Operating 100 hours without backlight on.
